GL-TG-HI330

$419.00 Regular price
/

  • In stock - departs in 1-2 business days
  • Inventory on the way
Size

The TotalGrow HI-Top light bar is an ideal, cost-effective, utility-incentive-friendly fit for greenhouse or indoor top-lighting with rugged construction and a narrow-profile body that mounts easily to support structures. Excellent efficacies are maximized by a versatile and highly effective grow spectrum, minimal shadowing, and optional side reflectors for uniform light delivery. Daisy-chain power and dimming control for low cost installation and operation.

TotalGrow High Intensity Top Light Grow Spectrum

Total Grow High Intensity Top Light Features:

  • 330W or 640W power at 2.5-2.8 μmol/J for the light intensities your plants need
  • Robust, reliable and streamlined design for simple utilization
  • Full spectrum for exceptional versatility
  • Shorten growth cycles
  • Improve yields and quality
  • Reliably produce year-round
  • Reduce 40-60% of energy compared to HPS
  • Long, low maintenance life
  • Excellent light uniformly
  • Easy installation with the included hangers
  • Versatile, efficacious, aesthetic spectrum

What's Included:

What's Sold Separately:

TotalGrow High Intensity Top Light Diagram

Specifications

HI-Top Product Specifications: HI-Top 330 HI-Top 640BF
Product Number TG33B4-R0J-28-D1-K0BJ6 TG64B4-R2J-25-D1-K0BA6
Output 910 μmol/s 1610 μmol/s
Efficacy 2.8 μmol/J 2.5 μmol/J
Power Consumption 330W 640W
Input Voltage (VAC) 100-277
100-277
Daisy-Chain Limit @120/240V 4 / 7 lights
2 / 4 lights
Current @120/240V 2.9 / 1.5 Amps 5.6 / 2.8 Amps
Length x Width x Height 25 x 3 x 4 inches 43 x 3 x 4 inches
Weight (lbs.) 6 (bar) + 4 (driver) = 10 11 (bar) + 6 (driver) = 17
Dimmable 0-10V + 12V aux power 0-10V + 12V aux power
Projected Service Life / Warranty 50,000 hours / 5 year 50,000 hours / 5 year
Waterproof IP66 IP66

General Usage Guidelines

Light Level Target Low Medium High
Plant Size Small Medium Large
Examples Germination, Cuttings, Microgreens Late Propagation, Lettuce, Basil Tomatoes
330W 640W 330W 640W 330W 640W
Supplemental (Greenhouse Sun + TotalGrow Lights) Light Intensity (PPFD) 50 μmol/m2/s 100 μmol/m2/s 300 μmol/m2/s
Coverage (sq. ft.) 170 325 80 170 25 50
Spacing (ft) 13 18 9 13 5 7
Height 7-11 10-15 5-8 7-11 3-5 4-6
Sole Source (100% TotalGrow Lighting) Light Intensity (PPFD) 120 μmol/m2/s 270 μmol/m2/s 1000 μmol/m2/s
Coverage (sq. ft.) 72 140 30 60 9 16
Spacing (ft) 8.5 12 5.5 8 3 4
Height 5-6 7-9 3-4 5-6 2 3
