Trac-Rite 944WL Roll-Up Door
Trac-Rite 944WL Roll-Up Door

Trac-Rite 944WL Roll-Up Door

DR-TR944WL10-X-10


$2,755.00 Sale price
/
20% Off*
Use code GIFT24 in checkout  *See details
  • Ships directly from manufacturer - departs in about 7 business days
Size
Amount

This product has a bulk discount available.

As part of Greenhouse Megastore's consistent goal of offering the best pricing and service possible, we are able to pass along savings by offering bulk discounts on select products. On these products we are able to offer larger amounts (like larger packs or cases) at a cheaper price-per-unit than individual items or smaller cases. If you have any questions, feel free to call 1-888-281-9337 and speak to a member of our team!

View all products with Bulk Discounts

Trac-Rite Model 944WL is ideal for the same residential, self-storage, and light-duty uses as our Model 944. In addition, Trac-Rite's windlock system provides maximum wind resistance for the model. As wind blows against the 944WL, the curtain's windlocks engage with the door guide for a strong interlocking grip. The continuous curtain of solid steel is durable and attractive.

Important Note

All Trac-Rite Doors need 23" top clearance.

Standard Features

All models are constructed using high-quality, durable materials for smooth operation and long life. From initial design to the delivered product, Trac-Rite provides a door that is built to last.

  • Strong, Durable Materials
    • Solid 26-gauge, Grade 80 rigid-rib steel curtain is durable, attractive, and requires little maintenance.
    • Door panels have a galvanized substrate and are coil-coated with a silicone polyester paint system for long life.
  • Smooth, Quiet Operation
    • Sturdy zinc-coated steel guides with polypropylene runners allow doors to glide easily.
    • Heavy-duty axle assembly is standard on all Trac-Rite doors, assuring smooth operation.
  • Easy to Install
    • Door nest is preassembled
    • Roll-up design offers easier installation.
    • Factory-punched holes in brackets and guides allow for quick installation.
    • Space Guard latch comes preinstalled on the curtain.
  • Customized
    • Every door is manufactured to the inch, at no extra charge, providing a perfect fit.
    • A full line of accessories is available to suit your needs.
  • Multiple Applications
    • Doors are ideal for residential, self-storage, and several commercial uses.
    • Popular applications include yard barns, counter shutters, farm buildings, car washes, and dock doors.
  • Low Maintenance
    • Roll-up design features no hinges or rollers that will wear out.
    • Felt tape protects exterior finish during operation.
    • Polypropylene guide runners provide years of maintenance-free service.
    • Supported by 30/25-year paint and 3-year material warranties.
  • Minimal Back Room Required
    • Roll-up design allows for minimal back room and reduced head room requirements, which is beneficial when working with high eave structures.
  • Rust Resistant
    • Aluminum bottom assembly, stainless steel bolts, and Thermal Plastic Elastomer (TPE) astragal provides corrosion resistance.
    • SpaceGuard latch and cylinder lock are rust resistant.
  • Complements Existing Buildings
    • Eleven attractive siliconized polyester paint colors complement any building.

Wind Load Ratings

Door Width 944 WL PSF / MPH
8' 0" 33.0 / 150
8' 8" 33.0 / 150
9' 0" 32.0 / 150
10' 0" 32.0 / 150
11' 0" 32.0 / 150

Color Options

Color Color Color Garnet Sunset OrangePolar Blue Shale Royal BlueCedar Red Evergreen Bright WhiteContinental Brown Desert Tan Iced White

Determining Your Needs

Follow these steps to pick to design a door for your specific needs:

  • Measure Framed Opening
  • Measure Mounting Surfaces
  • Measure Door Clearance
  • Select Door Model
  • Choose Accessories

Framed Openings

Measure your framed opening. Doors are custom made to 1" increments in both width and height.

FOR EXAMPLE: If your framed opening is 7'6" wide and 8'0" high, you would order a 7'6"W x 8'0"H (width first, height second) door.
A = Width
B = Height


Mounting Surfaces

Measure the mounting surface areas.
NOTE: All mounting surfaces must be flush.

Brackets 944 944WL 955/988 955WL/988WL C = Width 4"5"5"5"D = Height 7 1/2"6 1/2"13"13"Guides 944944WL955/988955WL/988WLE = Width 2" (4" Masonry)3" (5" Masonry)3" (5" Masonry)3" (5" Masonry)

Door Clearance

Measure the door clearance.
NOTE: Insulated doors require an additional 1" of back room and head room.

Model 944 944WL 955 955WL 988 988WL F = Back Room 18"19"19"
(20" for doors 9' 6" and higher)20"
(21" for doors 9'6" and higher)20"21"G = Head Room 15"
(16" for doors 7'1" and higher)15"
(16" for doors 7'1" and higher)21"
(22" for doors 9'6" and higher)22"
(23" for doors 9'6" and higher)22"23"H = Side Room 4"
(9" for chain host)5"
(9" for a chain host)5"
(9" for a chain hoist and 22" for a motor operator)5"
(9" for a chain hoist and 22" for a motor operator)7 1/2"
(for standard chain hoist) (22" for a motor operator)7 1/2"
(for standard chain hoist) (22" for a motor operator)

Door Model

Measure the mounting surface areas.
NOTE: All mounting surfaces must be flush.

Choose Model 944, 944WL, 955, 955WL, 988, or 988WL from the Door Model Selection Bar Graph. If there is overlap in door size options, consider how your door will be used. Larger door models have heavier springs, brackets, and guides. The "WL" (wind load) models may be needed when building codes require a specific PSF rating. *Call customer service at 1-888-281-9337 for more details on wind load ratings.


Additional Information

Installation

944WL Manual (PDF)

Warranty

All Trac-Rite doors hold a 30/25-year limited warranty includes chalking, fading, and rusting. In addition, there is a 3-year limited warranty on 944, 944WL, 955, 955WL, 988, and 988WL parts.
